TAC200
LTE CAT1 Long Battery Life Asset Tracker
TAC200 is a CAT1 long battery life asset tracker . It is designed upto 7 years battery life.
Related products
- LTE CAT1 with 2G fall back
- Upto 7 years battery life
- IP67 waterproof
- Built-in light sensor
|
Data support |
SMS (TEXT, PDU), Network protocols (TCP, UDP, TLS, MQTT*) |
|
Scheduled Report |
Sleep mode report frequency and Emergency mode report frequency |
| Alarms | Motion alarm, light alarm, low battery alarm |
| Temperature Monitoring |
BLE temperature sensor and humidity sensor |
| Protocol | High compatibility protocol, only one message for all products and events. Super easy for platform integration |
| Configuration Tool |
Web online configurator supports all OS and plug & play configuration |
| FOTA | Yes |
| BLE | BLE configuration, BLE debug, BLE firmware upgrading, BLE accessories |
|
General Specifications |
|
|
Dimensions |
92.5*48.2*29.65mm |
|
Weight |
145g |
| Voltage | 3.3V |
|
Operating Temperature |
-25℃~ +60℃ |
|
Standby Time |
7 years with 1 report per day |
|
Ingress Protection Rating |
IP67 |
|
Back-up Battery |
6400mAh (4*CR17335Ah batteries) |
|
Sleep Current |
<10uA |
|
GNSS Specifications |
|
| GNSS | BDS, GPS, GLONASS, Galileo, QZSS |
|
Tracking Sensitivity |
-165 dBM |
|
Position Accuracy(CEP) |
< 2m |
|
Velocity Accuracy |
0.1m/s |
| TTFF |
Cold Start: 26s |
|
Hot Start: 1s |
|
|
Reacquisition: 2s |
|
|
Network Specifications |
|
|
Frequency Bands (EU) |
GSM: B2/B3/B5/B8 LTE FDD: B1/B3/B5/B7/B8/B20/B28 |
|
Frequency Bands (LA) |
GSM: B2/B3/B5/B8 LTE FDD: B2/B3/B4/B5/B7/B8/B28/ B66 |
|
Data Transfer (Max)
|
LTE FDD (Cat.1): 10 Mbps (DL) / 5 Mbps (UL) |
|
GSM (GPRS): 85.6 Kbps (DL) / 85.6 Kbps (UL) |
|
|
GPRS: 85.6Kbps(DL),85.6Kbps(UL) (Option) |
|
|
Interface |
|
|
BLE |
BLE 5.4 |
|
Light Sensor |
Built-in light sensor |
|
Type-C |
Designed for firmware upgrade, configuration and debug |
